Stripper, cable, bushing only, for 2x2-4x4-WS68 tool, 10mm2 XLPE LV ABC, Ripley
Stripper, cable, bushing only, for 2x2-4x4-WS68 tool, 10mm2 XLPE LV ABC, Ripley


Code: RB-100
Brand: Ripley Tools
Product Details
Stripper, cable, bushing only, for 2x2-4x4-WS68 tool, 10mm2 XLPE LV ABC, Ripley


TEN Square Cut Cable Stripper Bushing

Part No. RB-100 - Cable Stripper Bushing for 10mm2 XLPE LV ABC

Large range of bushings suit common Australian cable sizes

Quick and simple bushing interchange for fast cable stripping

Bushings Suit the following Stripping Tools

  • Milwaukee - M18™ Battery Cable Stripper - Part No. M18BCS-0C
  • Ripley - Power Driven Stripper - Part No. WS68-3-8
  • Ripley - 4 x 4 Stripper - Part No. 36001H
  • Ripley - 2 x 2 Stripper - Part No. 36101H

Range of available bushings

TEN Part No.Square Cut Bushings to suit LV ABC
RB-10010mm² Al XLPE OH
RB-10116mm² Al XLPE OH
RB-20025mm² Al XLPE OH
RB-20135mm² Al XLPE OH
RB-30050mm² Al XLPE OH
RB-30170mm² Al XLPE OH
RB-40095mm² Al XLPE OH
RB-401120mm² Al XLPE OH
RB-500150mm² Al XLPE OH
TEN Part No.Square Cut Bushings to suit Underground
RB-10216mm² Cu XLPE/PVC LV UG (Olex)
RB-20235mm² Cu XLPE/PVC LV UG (Olex)
RB-30250mm² Cu XLPE/PVC LV UG (Olex)
TEN Part No.Square Cut Bushings to suit Building Cable
RB-10316mm² Cu PVC SDI V90 - Red (Olex)
RB-10316mm² Cu PVC SDI V90 - Black (Olex)
RB-30370mm² 19/2.14 Cu Green/Yellow Earth building wire
RB-600240mm² Cu Double Insulated
TEN Part No.Square Cut Bushings to suit PVC
RB-30450mm² Cu PVC 0.6/1kV - Black on White (Olex)
RB-30570mm² Cu PVC 0.6/1kV - Black on Clear (Olex)
RB-30570mm² Cu PVC 0.6/1kV - Black-White on Clear (Olex)
TEN Part No.Square Cut Bushings to suit Misc Cable
RB-30670mm² Cu XLPE / PVC, Black on White (Olex)
RB-402120mm² Cu XLPE / PVC, Black on Clear (Olex)
RB-501150mm² Cu, Black-White on Clear (Olex)
RB-502185mm² Cu, Black-White on Clear (Olex)
RB-502185mm² Cu, Black (Prysmian)
RB-501150mm² Al, Black (Olex)
RB-601240mm² Al XLPE / PVC, Black on Colour (Olex)
RB-700157mm² HD Al, Railway, 12 x 3.27 0.6/1KV V-90 L Electric Cable (Prysmian)
TEN Part No.Ripley Stripper Bodies & Accessories
WS68-3-8RIPLEY Power/Drill Driven Stripper
36001HRIPLEY 4 x 4 Stripper
36101HRIPLEY 2 x 2 Stripper
40110RIPLEY Bushing quick connect for above strippers
