Multi Tool Battery Hydraulic c/w 6 Tonne Die adaptor - 2 x Batteries - Charger, Crimp - Cut - Punch
Multi Tool Battery Hydraulic c/w 6 Tonne Die adaptor - 2 x Batteries - Charger, Crimp - Cut - Punch


Code: EK60UNVCFM-K
Brand: Klauke
Product Details
Kit, multi, battery hydraulic, b/tooth, 6T, UA22 adaptor, 2 x 4Ah 18v Li, Klauke


Kit Components

This item contains the following components:

  • One head for crimping, cutting and punching - one tool for all
  • Ideal in the assembly field where all common jobs can be carried out using one tool
  • Fast working due to 2-stage hydraulics
  • All tool data on view thanks to display and i-press® app

Features

  • All data can be easily read via Bluetooth
  • Universal head flip top style, rotatable
  • Simple and safe: One-button operating concept for controlling all tool functions
  • Effortless working due to balanced centre of gravity
  • LED for work area illumination
  • Simple and safe: Automatic retraction when operation is complete
  • Always ready-to-use thanks to battery charge and service display

EK60UNVCFMSpecification
Crimping Force 60kN
Stroke 42mm
Crimping Range 6 - 300mm²
Crimping Cycle 3 - 5 seconds (depending on cross-section)
Cutting Range max. 40mm diameter
Punching Capacity up to 64mm diameter round
Charging Time 45 minutes
Weight 4.8kg
